Overview

Reference for how large something will print at various scales. As well as the associated scale values that many programs use for scale factors.

Engineering scales are typically used for larger scale items, therefore, the scale is equalized to the middle of the table, with values above and below.

List of all scales (ordered by size)

#	FRACTION	UNIT	VALUE	VALUE	SCALE	RATIO
1	12	12″	12	1′-0″	12″ = 1′-0″	1:1
2	6	6″	12	1′-0″	6″ = 1′-0″	1:2
3	3	3″	12	1′-0″	3″ = 1′-0″	1:4
4	1.5	1 1/2″	12	1′-0″	1 1/2″ = 1′-0″	1:8
5	1	1″	12	1′-0″	1″ = 1′-0″	1:12
6	0.75	3/4″	12	1′-0″	3/4″ = 1′-0″	1:16
7	0.5	1/2″	12	1′-0″	1/2″ = 1′-0″	1:24
8	0.375	3/8″	12	1′-0″	3/8″ = 1′-0″	1:32
9	0.25	1/4″	12	1′-0″	1/4″ = 1′-0″	1:48
10	0.1875	3/16″	12	1′-0″	3/16″ = 1′-0″	1:64
11	0.125	1/8″	12	1′-0″	1/8″ = 1′-0″	1:96
12	1	1″	120	10′-0″	1″ = 10′-0″	1:120
13	0.09375	3/32″	12	1′-0″	3/32″ = 1′-0″	1:128
14	0.0625	1/16″	12	1′-0″	1/16″ = 1′-0″	1:192
15	1	1″	240	20′-0″	1″ = 20′-0″	1:240
16	0.046875	3/64″	12	1′-0″	3/64″ = 1′-0″	1:256
17	1	1″	360	30″-0″	1″ = 30′-0″	1:360
18	0.03125	1/32″	12	1′-0″	1/32″ = 1′-0″	1:384
19	1	1″	480	40′-0″	1″ = 40′-0″	1:480
20	1	1″	600	50′-0″	1″ = 50′-0″	1:600
21	1	1″	720	60′-0″	1″ = 60′-0″	1:720
22	0.015625	1/64″	12	1′-0″	1/64″ = 1′-0″	1:768
23	1	1″	960	80′-0″	1″ = 80′-0″	1:960
24	1	1″	1200	100′-0″	1″ = 100′-0″	1:1200

Engineering Scales Printed Size

1”=10’-0”

PRINTED SIZE		REAL LIFE SIZE
16.0000	inch	160	feet
8.0000	inch	80	feet
4.0000	inch	40	feet
2.0000	inch	20	feet
1.0000	inch	10	feet
0.5000	inch	5	feet
0.2500	inch	2.5	feet
0.1250	inch	1.25	feet
0.0625	inch	0.625	feet

1”=20’-0”

PRINTED SIZE		REAL LIFE SIZE
16.0000	inch	320	feet
8.0000	inch	160	feet
4.0000	inch	80	feet
2.0000	inch	40	feet
1.0000	inch	20	feet
0.5000	inch	10	feet
0.2500	inch	5	feet
0.1250	inch	2.5	feet
0.0625	inch	1.25	feet

1”=30’-0”

PRINTED SIZE		REAL LIFE SIZE
16.0000	inch	480	feet
8.0000	inch	240	feet
4.0000	inch	120	feet
2.0000	inch	60	feet
1.0000	inch	30	feet
0.5000	inch	15	feet
0.2500	inch	7.5	feet
0.1250	inch	3.75	feet
0.0625	inch	1.875	feet

1”=40’-0”

PRINTED SIZE		REAL LIFE SIZE
16.0000	inch	640	feet
8.0000	inch	320	feet
4.0000	inch	160	feet
2.0000	inch	80	feet
1.0000	inch	40	feet
0.5000	inch	20	feet
0.2500	inch	10	feet
0.1250	inch	5	feet
0.0625	inch	2.5	feet

1”=50’-0”

PRINTED SIZE		REAL LIFE SIZE
16.0000	inch	800	feet
8.0000	inch	400	feet
4.0000	inch	200	feet
2.0000	inch	100	feet
1.0000	inch	50	feet
0.5000	inch	25	feet
0.2500	inch	12.5	feet
0.1250	inch	6.25	feet
0.0625	inch	3.125	feet

1”=100’-0”

PRINTED SIZE		REAL LIFE SIZE
16.0000	inch	1600	feet
8.0000	inch	800	feet
4.0000	inch	400	feet
2.0000	inch	200	feet
1.0000	inch	100	feet
0.5000	inch	50	feet
0.2500	inch	25	feet
0.1250	inch	12.5	feet
0.0625	inch	6.25	feet

1”=500’-0”

PRINTED SIZE		REAL LIFE SIZE
16.0000	inch	8000	feet
8.0000	inch	4000	feet
4.0000	inch	2000	feet
2.0000	inch	1000	feet
1.0000	inch	500	feet
0.5000	inch	250	feet
0.2500	inch	125	feet
0.1250	inch	62.5	feet
0.0625	inch	31.25	feet

1”=1000’-0”

PRINTED SIZE		REAL LIFE SIZE
16.0000	inch	16000	feet
8.0000	inch	8000	feet
4.0000	inch	4000	feet
2.0000	inch	2000	feet
1.0000	inch	1000	feet
0.5000	inch	500	feet
0.2500	inch	250	feet
0.1250	inch	125	feet
0.0625	inch	62.5	feet

1”=2500’-0”

PRINTED SIZE		REAL LIFE SIZE
16.0000	inch	40000	feet
8.0000	inch	20000	feet
4.0000	inch	10000	feet
2.0000	inch	5000	feet
1.0000	inch	2500	feet
0.5000	inch	1250	feet
0.2500	inch	625	feet
0.1250	inch	312.5	feet
0.0625	inch	156.25	feet

1”=5280’-0”

PRINTED SIZE		REAL LIFE SIZE
16.0000	inch	84480	feet
8.0000	inch	42240	feet
4.0000	inch	21120	feet
2.0000	inch	10560	feet
1.0000	inch	5280	feet
0.5000	inch	2640	feet
0.2500	inch	1320	feet
0.1250	inch	660	feet
0.0625	inch	330	feet
